Specs

Display

Panel Type

IPS-Type LCD

Display Size

5.5" / 14.0 cm

Native Resolution

1920 x 1080

Aspect Ratio

16:9

Viewing Angle

Horizontal: 160° (80/80)

Vertical: 160° (80/80)

Touchscreen

Yes

Maximum Brightness

500 nits / cd/m2

Contrast Ratio

1000:1

HDR Support

No

Inputs/Outputs

Video I/O

1x HDMI Input

1x HDMI Output

Audio I/O

1x 1/8" / 3.5 mm Headphone Output

Built-In Speaker

No

Power I/O

1x Barrel 2.1 mm (12 VDC) Input

1x Barrel (8 VDC) Output

1x USB-C (5 VDC) Input

Media/Memory Card Slot

Single Slot: SD (Unspecified Type) [LUT Upload Only]

Wireless

Wi-Fi

No

Bluetooth

No

Mobile App Compatible

No

Format Support

Video Format

HDMI

DCI 4K: 24

UHD 4K: 30/29.97/25/24/23.98

1080p: 60/59.94/50/30/29.97/25/24/23.98

1080i: 60/59.94/50

1080PsF: 24/23.98

720p: 60/59.94/50/30/29.97/25/24/23.98

576p

576i

480p

480i

Show More

Power

Input Power

7 to 24 VDC

Battery

1x L-Series/LP-E6 Combination Mount on Fixed Plate

Power Consumption

9 W

Mounting

Tripod/Accessory Mounting

Bottom/Left/Right

1x 1/4"-20 Female

General

Environmental Resistance

No

Operating Conditions

12 to 87°F / -20 to 55°C

Storage Conditions

-22 to 149°F / -30 to 65°C

Dimensions

5.8 x 3.7 x 0.8" / 14.8 x 9.3 x 2 cm

Weight

0.52 lb / 235.00 g

Packaging Info

Package Weight

1.47 lb
